COSEL BRFS系列DC-DC電源模塊介紹及替代產品

發布時間：2024-08-21 09:48:24 瀏覽：605

　　COSEL BRFS系列DC-DC電源模塊具有一下特征：

　　? 小尺寸、高效率的非隔離式DC-DC轉換器。

　　? 寬輸入電壓：4.5V至14.0V。

　　? 通過穩健的控制實現快速瞬態響應。

　　? 內置遠程開/關、電源良好、啟動順序。

　　? 內置過流和熱保護(自動恢復型)功能。

產品型號參數介紹：

MODEL		BRFS30	BRFS40	BRFS60	BRFS60S	BRFS100	BRFS120	BRFS150
MAX OUTPUT CURRENT[A		30.0	40.0	60.0	60.0	100.0	120.0	150.0
DC OUTPUT		0.8-3.63V	0.6-2.0V	0.7-2.0V	0.6-2.0V	0.7-2.0V	0.6-1.8V	0.6-1.8V*
SPECIFICATIONS
	MODEL	BRFS30	BRFS40	BRFS60	BRFS60S	BRFS100	BRFS120	BRFS150
INPUT	VOLTAGE[V]	DC4.5-14.0
	CURRENT[A]	3.41 typ	4.52 typ	6.82 typ	6.71 typ	11.24 typ	13.50 typ	16.90 typ
	EEEICIENCY[%]	88.0 typ	88.5 typ	88.0 typ	89.5typ	89.0 typ	89.0 typ	89.0 typ
0UTPUT	VOLTAGE[V]	0.8-3.63	0.6-2.0	0.7-2.0	0.6-2.0	0.7-2.0	0.6-1.8	0.6-1.8*7
	CURRENT[A	30	40	60	60	100	120	150
	LINE REGULATIO N[mV]	5
	LOAD REGULATION [mV]	5
	RIPPLE[mVp-p]	25
	BIPPLE NOISE [mVp-p]	50
	OUTPUTVOLTAGE SETTING[%Vo]	±1
	DRIFT[mV	5
	START-UP TIME[ms	8.0 typ			12.0 typ*	8.0 typ	12.0 typ*B
	OUTPUTVOLTAGE [V] ADJUSTMENT RANGE	Adjustable by external resistor
	OUTPUTVOLTAGE [V] ADJUSTMENT RANGE	0.8-3.63	0.6-2.0	0.7-2.0	0.6-2.0	0.7-2.0	0.6-1.8	0.6-1.8*7
	0UTPUTVOLTAGE TOTAL REGULATON NV]	±3
PBOTECTION CIRCUIT AND OTHERS	OVERCURREN TPROTECTION	Works over 105%of rating (auto recovery type)
	REMOTE SENSING	Available(+S only)		Available	halahe(4Somhy	Available
	REMOTE ON/OFF	Available Negative logic L:ON,H:OFF
SOLATION	INPUT-OUTPUT	non-isolated
ENVIRON MENT	0PERATINGTEMP ,HUMID.AND ALTITUDE	-40 to+85℃,20-95%RH (Noncondensing)(Refer to "Derating")3,000m(10,000feet)max
	STORAGETEMP., HUMD.AND ALTITUDE	-40 to+100℃,20-95%RH (Non condensing),9,000m (30,000feet)max
	VIBRATION	10-55Hz,49.0m/s2(5G),3minutes period,60minutes each along X,YandZ axis
	IMPACT	196.1m/s2(20G),11ms,once each along X,Y andZ axis
SAFETY	AGENCY APPROVALS	UL60950-1,C-UL (CSA60950-1),EN62368-1
OTHERS	CASE SIZE /WEIGHT	33.0X9.5X13.5mm 1.3X0.37X0.53 nches](WXHXD)/ 10g max	33.0X10.9X13.5mm [1.3X0.43X053 nches](WXHXD)/ 12g max	33.0X8.0X22.9mm 1.3X0.31X0.9 inches](WXHXD)/ 15g max	33.0X12.7X13.5mm [1.3X0.5X0.53 nches](WXHXD)/ 12g max	38.0X8.5X27.7mm [1.5X0.33X109 nches](WXHXD)/ 22g max	33.0X12.7X22.9mm 1.3X0.5X0.9 nches](WXHXD)/ 14g max	38.0X13.8X27.7mm [1.5X0.54X1.09 nches](WXHXD)/ 21g max
OTHERS	C00LING METHOD	Convection/Forced air

注：深圳立維創展提供COSEL BRFS系列DC-DC電源模塊替代方案，價格優惠，現貨。
